Specification | |
|---|---|
|
Operating pressure |
1150 psi |
|
Hydraulic interface |
Ps，R:MS33649-8 |
|
Internal leakage of hydraulic switch |
Reverse 3000 psi Internal leakage < 10 cc/min |
|
Flow servo control |
Forward and reverse 77.5 ~ 94.5 L/min |
|
Total internal leakage at 0 flow rate |
< 600 cc/min |
|
Starting voltage of three-way valve |
24 VDC@1 Amp |
|
Pressure converter input voltage |
± 15 VDC, current < 42 mA |
|
Pressure converter input oil pressure difference 1150psi |
0.0137 ± 0.0019 VDC |
|
LVDT |
Primary side input 26 VRMS Secondary side output > 7 VDC@stroke 6.5mm Power < 1.5 W |
|
Differential pressure across both ends of the small spool valve |
< 410 psi |
|
Energy |
Use hydraulic oil, MIL-H-46170 |
|
Steady state mode/ Activate the three-way valve |
|
|
Power mode/ Turn off the three-way valve |
|
|
Servo control can be adjusted to C1 and C2 flow rate < 5 cc |
|
|
Country Code |
1025YETA59809 |
